Quantum X Bio - 2PP 3D Printer
The Quantum X Bio is a ultra high-resolution micro- and meso-scale 2-photon polymerization 2.5D and 3D printer. We have this instrument located in an UV-safe ISO class 6 cleanroom to keep dust and contaminants out of your prints
- Small (63x), medium (25x), large (10x), and extra-large (5x) feature set objectives
- Temperature and humidity controllable bioprinting chamber
- DescribeX (3D prints) and GrayScribeX (2.5D prints) software
- Nearly endless photoink options including IPX and IP photoresins from Nanoscribe, biopolymer inks from BIO INX and Advanced Biomatrix, and the ability to generate and print with your own custom photoresins
Form 3 & Form 4B - SLA 3D Printer
Our Formlabs Form 3 and Form 4B stereolithography (SLA) 3D printers allow us to print rapidly and accurately print macro-scale devices and prototypes.
- Wide variety of resins choices including biomedical and dental resins with the Form 4B
- Layer heights as low as 25 µm, laser spot size of 85 µm (Form 3), pixel size 50 µm (Form 4B)
Phenom ProX - SEM/EDS
The Thermo Scientific Phenom ProX scanning electron microscope (SEM) with energy-dispersive X-ray diffraction (EDS) and secondary electron detector (SED) is a desktop SEM for high resolution imaging and elemental analysis of samples.
- Stages: Conductive sample stage, non-conductive sample (charge reduction) stage, and actively-cooled stage (≥-25°C, for frozen samples)
- Luxor GoldCoater sputter coater for optional sample preparation
- EDS allows for element identification, SED allows for improved imaging of topology
DHR-II - Hybrid Rheometer/Mechanical Analyzer
Our TA Instruments DHR-II Rheometer/Dynamic Mechanical Analyzer allows users to perform rheology experiments or perform mechanical testing on samples.
- Rheology & dynamic mechanical analysis
- 8, 20, and 40 mm diameter geometries
- Tension fixture for mechanical testing
- Peltier plate & concentric cylinder for precise active temperature control
- Normal Force: 50 N max, 5 mN sensitivity, 0.5 mN resolution
- Torque: 0.5 nN·m - 200 mN·m, 0.05nN·m resolution
- Step time: 5 ms rate, 15 ms strain
Venus 50HF - RIE/Plasma Chamber
The PlasmaEtch Venus 50HF Plasma Chamber can be used for plasma cleaning, reactive ion etching (RIE), surface modification and activation, plasma bonding, and more. Learn more.
- 125W 13.56 MHz power supply with automatic RF matching, dual gas controller, and automated processes sequencing
- Process gasses: Oxygen, Argon, and/or CF4; Nitrogen purge
- 11.25W x 15D x 5H cm usable chamber space
J257 - Refractometer
- Rudolf Research Analytical J257 Refractometer
- RI 1.26-1.72 (±0.0001) at 589.3 nm
- Peltier temp control: 15-70ºC
- Programmable
SCS 6808P - Spin Coater
The Specialty Coating Systems 6808P spin coater is a programmable spin coater allowing for coating substrates with thin films in a controllable, repeatable manner.
- Kept in fume hood with UV-safe window and light coating for photosensitive applications
UV-Safe Fume Hood
Our UV-safe fume hood is equipped with yellow-light filters which block UV light to allow for work with volatile photoreactive chemicals and development of 3D prints.
Other
- Fisherbrand UV Crosslinker with adjustable height for UV curing and crosslinking of photoresins, photoresist, and other UV-reactive components
- 254, 306, and 368 nm bulbs
- Laxco LMS-Z230P-MZ32 stereomicroscope with SeBaCam20C camera
- Vacuum oven for molecular vapor deposition (MVD) of volatile coatings onto plasma activated surfaces
